RC22M All-in-One Met Sensor
Highlights:
- Ideal for commercial and industrial (C&I) and community solar projects. Meets requirements for Class B met station according to IEC 61724-1.
- RC22M is an all-in-one met sensor that provides high accuracy irradiance measurements, just like its parent product RC22 PV Reference Cell, but also includes optional inputs for wind speed and two Pt1000 RTD temperature sensors.
- Pt1000 RTDs can include either our easy-to-install self-adhesive back-of-module (BOM) sensor or our ambient temperature sensor, with or without a radiation shield.
- Integrated features support multiple mounting configurations for weather / meteorological stations.
- The ultra compact design allows easy mounting anywhere, including the rear side of your bifacial array.
- Wide-dynamic range, ultra-low zero offset, and dual calibration at both 1000 W/m2 (STC) and 135 W/m2 (BSTC) provide accurate measurements over the full range of irradiances seen by bifacial systems.
- Unique glass-to-edge surface design eliminates excess soiling versus conventional reference cells.
- Communicates via Modbus RTU over RS485.
Outputs:
- Irradiance
- Wind Speed
- Module Temperature
- Ambient Temperature
- Cell short-circuit current
- Cell temperature
Applications:
- Measure irradiance, wind speed, and temperature to monitor solar performance ratio for operations and maintenance
